AYA
No. 4

An Anson & Deeley boxlock ejector for game shooting

No. 4 · UKNº4/53 · UKNo. 4 Deluxe · US

Drawing of an AYA No. 4 from the right: side-by-side barrels, a scroll-engraved boxlock, double triggers, a straight-hand walnut stock and a fore-end with a button release.
Drawing: 20-bore Deluxe, 28 in, right side

he AYA No. 4 is an Anson & Deeley ejector for game shooting.1, 2 The Nº4/53 has a straight-hand walnut , light scroll and a concave .2

The No. 4 has a replaceable , disc-set firing pins and double triggers.2 Its use Southgate over-centre cam work.3 The De Luxe adds rose and scroll , grade 1 walnut and a gold initial oval, while the RA has rounded contours.4, 5

Specifications

20-bore

HingeReplaceable 6, 7
LockingDouble locking mechanism6, 7
LockworkAnson & Deeley 6, 7
TriggerDouble triggers; De Luxe has an articulated front 6, 7
EjectorsSouthgate over-centre cam 6, 7
Made inEibar, Spain8
Introducedby 19859, 10
Bore20-bore
Chambers70 mm (2¾ in)
Barrels28 in
Chokes¼ and ½; fixed

11 Compare specifications

Specifications

ConfigurationBoreChambersBarrels, inFore-endGradeChoke systemYearsWeightMarketsStockFinish
No. 4 Deluxe; test gun1120-bore70 mm (2¾ in)28Anson button releaseNo. 4 Deluxe; test gun¼ and ½; fixed2016Straight grip; Anson button release fore-end; 381 mm pullColour case hardened; scalloped action; Scroll engraving
Nº4/5313, 1012-boreNº4/532015Straight gripColour hardened, old silver or white action; Light scroll engraving; wood grade 2
Nº4/5313, 1016-boreNº4/532015Straight gripColour hardened, old silver or white action; Light scroll engraving; wood grade 2
Nº4/5313, 1020-boreNº4/532015Straight gripColour hardened, old silver or white action; Light scroll engraving; wood grade 2
Nº4/5313, 1028-boreNº4/532015Straight gripColour hardened, old silver or white action; Light scroll engraving; wood grade 2
Nº4/5313, 10.410Nº4/532015Straight gripColour hardened, old silver or white action; Light scroll engraving; wood grade 2
Nº4 De Luxe14, 1012-bore28Nº4 De Luxe20153.062 kg (6 lb 12 oz; catalogue, 28 in)Straight gripColour hardened, old silver or white action; Rose and scroll engraving; wood grade 1
Nº4 De Luxe14, 1016-bore28Nº4 De Luxe2015Straight gripColour hardened, old silver or white action; Rose and scroll engraving; wood grade 1
Nº4 De Luxe14, 1020-bore28Nº4 De Luxe2015Straight gripColour hardened, old silver or white action; Rose and scroll engraving; wood grade 1
Nº4 De Luxe14, 1028-bore28Nº4 De Luxe2015Straight gripColour hardened, old silver or white action; Rose and scroll engraving; wood grade 1
Nº4 De Luxe14, 10.41028Nº4 De Luxe2015Straight gripColour hardened, old silver or white action; Rose and scroll engraving; wood grade 1
Nº4 RA15, 1012-boreNº4 RA2015Straight gripColour hardened, old silver or white action; Light scroll engraving; wood grade 1
Nº4 RA15, 1016-boreNº4 RA2015Straight gripColour hardened, old silver or white action; Light scroll engraving; wood grade 1
Nº4 RA15, 1020-boreNº4 RA2015Straight gripColour hardened, old silver or white action; Light scroll engraving; wood grade 1
Nº4 RA15, 1028-boreNº4 RA2015Straight gripColour hardened, old silver or white action; Light scroll engraving; wood grade 1
Nº4 RA15, 10.410Nº4 RA2015Straight gripColour hardened, old silver or white action; Light scroll engraving; wood grade 1
Nº4 L16, 1012-bore28Nº4 L2015Straight gripOld silver action; Floral and scroll engraving
Nº4 L16, 1016-bore28Nº4 L2015Straight gripOld silver action; Floral and scroll engraving
Nº4 L16, 1020-bore28Nº4 L2015Straight gripOld silver action; Floral and scroll engraving
Nº4 L16, 1028-bore28Nº4 L2015Straight gripOld silver action; Floral and scroll engraving
No. 4 Deluxe17, 1012-bore26, 27, 28ClassicNo. 4 DeluxeImproved cylinder / modified or modified / full1985USStraight grip; Classic fore-endColour case hardened action
No. 4 Deluxe17, 1020-bore26, 27, 28ClassicNo. 4 DeluxeImproved cylinder / modified or modified / full1985USStraight grip; Classic fore-endColour case hardened action
No. 4 Deluxe17, 1028-bore26, 27, 28ClassicNo. 4 DeluxeImproved cylinder / modified or modified / full1985USStraight grip; Classic fore-endColour case hardened action
No. 4 Deluxe17, 10.41026, 27, 28ClassicNo. 4 DeluxeImproved cylinder / modified or modified / full1985USStraight grip; Classic fore-endColour case hardened action
Game
Game18, 10.41076 mm (3 in)28SplinterNo. 4; test gun¼ and ½; fixed20222.381 kg (5 lb 4 oz; measured, 28 in)UKSplinter fore-end; 381 mm pullColour case hardened action; Border scroll and floral motifs engraving

Scroll for more columns.

Identify and date

The No. 3 shares the Anson & Deeley pattern but lacks .1 The No. 2 has plates and gold-lined cocking indicators.19 The No. 4's replaceable distinguishes it from the fixed-pin Webley & Scott 700.3

Spanish appear on essential parts, including the barrels and breech closure.20 The tested Deluxe 20- carries 70 mm and 1370 BAR proof information, with 15.8 marked as the diameter in both barrels.21 A symbol on smoothbore barrels records the year of proof.22 In Eibar's official table, A1 stands for 1955, A2 for 1981 and A*3 for 2007.23

WhereMarkings
Barrels and breech closureSpanish 24
Smoothbore barrelsSymbol for the year of proof25

Proof date

The 1979 regulation requires smoothbore barrels to carry a symbol for the year of proof. Later codes in the official table carry an asterisk, as in A*1, and the first series includes CH, LL and Ñ.22, 23

Proof date codes

Before you buy

  1. Measure the and match them to your shooting; a used-gun review describes No. 4s as fairly tightly choked.26
  2. Have both demonstrated.
  3. Ask a specialist to assess barrel straightness, dimensions and wall thickness.
  4. Check that the fits you; the Deluxe 20- tested had a 15-inch pull and 2½-inch at .27
  5. Read the gun's own length: the Deluxe 20- tested has 70 mm chambers, while the .410 tested has three-inch chambers.21, 28
  6. Inspect the for cracks, the for looseness and the gun for fundamental alterations.29

History

The King brothers brought a Westley Richards Anson & Deeley to AYA as a pattern for its British range.30 Their work helped establish the No. 4 and No. 4 De Luxe alongside the firm's sidelocks.30 In the US, Gun Digest's 1985 annual lists the No. 4 Deluxe.31, 32

AYA's 2015 centenary catalogue lists the Nº4/53, De Luxe, RA and L.33, 2, 4, 5, 34 The RA has a round , while the L carries floral and scroll .5, 34 Shooting Times reported in 2022 that the No. 4 remained in production.1

DateChangeObservable feature
2015AYA lists the round- Nº4 RA35Rounded with a split bottom plate

Sources

  1. Shooting Times: AYA's British history and numbered models, no3-no4-and-yeoman. Shooting Times / ShootingUK, 2022-10-31. magazine · Archive
  2. AYA centenary catalogue: history and model specifications, no4-53. Aguirre y Aranzabal, 2015. maker catalogue · Archive
  3. Sporting Gun: AYA No. 4 .410 test, design-origins. Sporting Gun / ShootingUK, 2022-06-15. magazine · Archive
  4. AYA centenary catalogue: history and model specifications, no4-de-luxe. Aguirre y Aranzabal, 2015. maker catalogue · Archive
  5. AYA centenary catalogue: history and model specifications, no4-ra. Aguirre y Aranzabal, 2015. maker catalogue · Archive
  6. AYA centenary catalogue: history and model specifications, pp. 12–13, No4-53; No4 De Luxe. Aguirre y Aranzabal, 2015. maker catalogue · Archive
  7. Sporting Gun: AYA No. 4 .410 test, Design origins. Sporting Gun / ShootingUK, 2022-06-15. magazine · Archive
  8. AYA centenary catalogue: history and model specifications, Revival and Otaola; British models. Aguirre y Aranzabal, 2015. maker catalogue · Archive
  9. Gun Digest 1985: AYA XXV BL/SL and No. 4 Deluxe US listings, page 385, p. 385, Edition citation; No4 Deluxe listing. Gun Digest; court compendium hosted by Michel & Associates, 1984. book · Archive
  10. Shooting Times: AYA's British history and numbered models, No3 No4 and Yeoman. Shooting Times / ShootingUK, 2022-10-31. magazine · Archive
  11. Gun Mart: AYA No 4 Deluxe in 20 bore, Test configuration; Barrels and proof; Stock and fore-end; Specification table. Gun Mart, 2016-12-13. magazine · Archive
  12. AYA centenary catalogue: history and model specifications, p. 12, No4-53. Aguirre y Aranzabal, 2015. maker catalogue · Archive
  13. AYA centenary catalogue: history and model specifications, No4-53. Aguirre y Aranzabal, 2015. maker catalogue · Archive
  14. AYA centenary catalogue: history and model specifications, No4 De Luxe. Aguirre y Aranzabal, 2015. maker catalogue · Archive
  15. AYA centenary catalogue: history and model specifications, No4 RA. Aguirre y Aranzabal, 2015. maker catalogue · Archive
  16. AYA centenary catalogue: history and model specifications, p. 15, No4 L. Aguirre y Aranzabal, 2015. maker catalogue · Archive
  17. Gun Digest 1985: AYA XXV BL/SL and No. 4 Deluxe US listings, page 385, p. 385, No4 Deluxe listing; Edition citation. Gun Digest; court compendium hosted by Michel & Associates, 1984. book · Archive
  18. Sporting Gun: AYA No.4 .410 barrel and stock specifications, Test weight and action; Barrels; Stock. Sporting Gun / ShootingUK, 2022-06-15. magazine · Archive
  19. AYA No. 2: introduction, relationship to No. 1 and specifications, standard-features. Aguirre y Aranzabal. maker website · Archive
  20. Spain: portable firearms proof regulation, 19 February 1979, mark-locations. Boletín Oficial del Estado / Ministerio de Defensa, 1979-02-19. proof house · Archive
  21. Gun Mart: AYA No 4 Deluxe in 20 bore, barrels-and-proof. Gun Mart, 2016-12-13. magazine · Archive
  22. Spain: portable firearms proof regulation, 19 February 1979, date-symbol-on-barrels. Boletín Oficial del Estado / Ministerio de Defensa, 1979-02-19. proof house · Archive
  23. BOPE: official letter and year table, code-table. Banco Oficial de Pruebas de Eibar. proof house · Archive
  24. Spain: portable firearms proof regulation, 19 February 1979, Mark locations. Boletín Oficial del Estado / Ministerio de Defensa, 1979-02-19. proof house · Archive
  25. Spain: portable firearms proof regulation, 19 February 1979, Date symbol on barrels. Boletín Oficial del Estado / Ministerio de Defensa, 1979-02-19. proof house · Archive
  26. ShootingUK: AYA No.4 and used all-round rivals, webley-and-no4. ShootingUK, 2012-10-24. magazine · Archive
  27. Gun Mart: AYA No 4 Deluxe in 20 bore, stock-and-fore-end. Gun Mart, 2016-12-13. magazine · Archive
  28. Sporting Gun: AYA No.4 .410 barrel and stock specifications, barrels. Sporting Gun / ShootingUK, 2022-06-15. magazine · Archive
  29. ShootingUK: AYA No.4 and used all-round rivals, inspection. ShootingUK, 2012-10-24. magazine · Archive
  30. AYA centenary catalogue: history and model specifications, british-models. Aguirre y Aranzabal, 2015. maker catalogue · Archive
  31. Gun Digest 1985: AYA XXV BL/SL and No. 4 Deluxe US listings, page 385, no4-deluxe-listing. Gun Digest; court compendium hosted by Michel & Associates, 1984. book · Archive
  32. Gun Digest 1985: AYA XXV BL/SL and No. 4 Deluxe US listings, page 385, edition-citation. Gun Digest; court compendium hosted by Michel & Associates, 1984. book · Archive
  33. AYA centenary catalogue: history and model specifications, centenary. Aguirre y Aranzabal, 2015. maker catalogue · Archive
  34. AYA centenary catalogue: history and model specifications, no4-l. Aguirre y Aranzabal, 2015. maker catalogue · Archive
  35. AYA centenary catalogue: history and model specifications, p. 14, No4 RA. Aguirre y Aranzabal, 2015. maker catalogue · Archive
